Experience eco-friendly driving with the 2017 Toyota Corolla 1.8L CVT Hybrid Pioneer Edition. This modified trim features Toyota's hybrid synergy drive (1.8L Atkinson-cycle engine + electric motor) for exceptional EPA 52 MPG city/48 MPG highway efficiency. The sunroof-free design prioritizes value and weight reduction, while standard amenities include keyless entry, Bluetooth connectivity, and Toyota Safety Sense™ P. With its silent electric mode, regenerative braking, and low emissions, this hatchback-inspired hybrid is ideal for eco-conscious buyers seeking maximum savings without compromising reliability.
| Basic parameters+B3:C31B3:C32B3:C33B3:C3B3:C67 | |
| Manufacturer | FAW Toyota |
| Vehicle type | Compact car |
| Energy type | Hybird |
| Emission level | China V |
| Maximum power (kW) | – |
| Maximum torque (N · m) | – |
| Transmission | E-CVT Continuously Variable Transmission |
| engine | 1.8L 99HP L4 |
| Electric motor (Ps) | 72 |
| Length * Width * Height (mm) | 4630*1775*1485 |
| Official 0-100km/h acceleration (s) | – |
| Maximum speed (km/h) | 180 |
| NEDC comprehensive fuel consumption (L/100km) | 4.2 |
| Curb weight (kg) | 1375 |
| Maximum Full Load Mass (kg) | – |
| Car body | |
| Length (mm) | 4630 |
| Width (mm) | 1775 |
| Height (mm) | 1485 |
| Wheelbase (mm) | 2700 |
| Front wheelbase (mm) | 1535 |
| Rear wheelbase (mm) | 1535 |
| Minimum ground clearance under full load (mm) | – |
| Body structure | Sedan |
| Number of seats (units) | 5 |
| Fuel tank capacity (L) | 45 |
| Trunk volume (L) | – |
| Drag coefficient (Cd) | – |
| Engine | |
| Engine model | 8ZR-FXE |
| Displacement (mL) | 1798 |
| Displacement (L) | 1.8 |
| Air intake form | Naturally aspirated |
| Cylinder arrangement | L |
| Number of cylinders (pcs) | 4 |
| Number of valves per cylinder (pcs) | 4 |
| Compression ratio | 13.1 |
| Valve train | DOHC |
| Cylinder diameter (mm) | 80.5 |
| Travel distance (mm) | 88.3 |
| Maximum horsepower (Ps) | 99 |
| Maximum power (kW) | 73 |
| Maximum power speed (rpm) | 5200 |
| Maximum torque (N · m) | 142 |
| Maximum torque speed (rpm) | 4000 |
| Maximum net power (kW) | – |
| Engine specific technology | VVT-i |
| Energy type | Hybird |
| Oil standard use | 92# (China) |
| Oil supply method | Multi-point EFI system |
| Cylinder head material | Aluminum Alloy |
| Cylinder material | Aluminum Alloy |
| Emission level | China V |
| Chassis Steering | |
| Drive mode | ●Front-engine |
| Front suspension type | ●McPherson independent suspension |
| Rear suspension type | ●Torsion beam non- independent suspension |
| Assistance type | ●Electric power assist |
| Vehicle body structure | Load-bearing |
| Brake type | |
| Front brake type | ●Vented Disc |
| Rear brake type | ●disc style |
| Parking brake type | ●Handbrake |
| Front tire specifications | ●195/65 R15 |
| Rear tire specifications | ●195/65 R15 |
| Spare tire specifications | ●Non full size |
| Regenerative bracking | ● All Hybrid |
| Electric Motor | |
| Motor type | Permanent magnet/synchronous |
| Total power of electric motor (kW) | 53 |
| Total torque of electric motor (N · m) | 207 |
| Maximum power of front motor (kW) | 53 |
| Maximum torque of front motor (N · m) | 207 |
| Battery/Charging | |
| Battery type | NiMH battery |
| abbreviation | E-CVT continuously variable transmission |
| Number of gears | Continuously variable speed |
| Gearbox Type | Electronic continuously variable transmission (E-CVT) |
